SP1482 DUNLOP Flange Type Air Spring 6''X2 Double Convoluted Air Lift Ride Bag

SP1482 DUNLOP Flange Type Air Spring 6''X2 Double Convoluted Air Lift Ride Bag For Industrial Inspection Equipment

Product Description

GUOMAT 6x2 Flange Industrial Air Spring Technical Data

Cover Plate Diameter: Ø153.5mm

Gas Hole: G1/2

Screw Teeth: 4-M10

Center Distance Between Screw Teeth: Ø127mm

The Rubber Bellow Natural Diameter: Ø159mm

Natural Height: 135.5mm

DUNLOP 6''X2 Rubber Air Bellow Dimensions

Maximum Diameter: 168mm

Space Required: 180mm

Minimum Height: 73mm

Maximum Height: 170mm

Total Stroke: 97mm

Static Height: 120mm

Effective Area at Static Height: 140cm²

Bellows Weight: 2.25KG

Maximum Working Pressure: 8bar

Burst Pressure: 40bar

Maximum Angle Between Top and Bottom Plates: 15°

Maximum Axial Offset: 10mm

Application of Air Spring

• Precision Electronic Equipment
• Motor and Blower
• Industrial Washing Machine
• Compressor
• Vibration Screen
• Belt Tension Equipment
• Lifter(jockey)
• Packing Press
• Paper Machine Press

About us

We always focus on the development of automotive components, and provide you with quality products and competitive prices.
If you are interested in our products, we are pleased to offer you our best quotation. If you have any question, please do let me know
We are looking forward to establishing business with you.

1. OEM Manufacturing welcome: Product, Package...

2. Sample order is available. If you make a large order after got the sample, we will return you the sample fee as discount.

3. We will reply you for your inquiry in 24 hours.

4. After sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.

SP1482 Air Spring

6''X2 Double Convoluted Air Spring

SP1482 DUNLOP Flange Type Air Spring 6''X2 Double Convoluted Air Lift Ride Bag Images
